Full Auto Rotary Filter Paper Pleating Machine BK-PLGT-600N
As leading filter paper pleating machine manufacturers, we provide advanced solutions that streamline the pleating process. Our BK-PLGT-600N is used for pleating and forming the HDAF filter element.
- Pre-slitter uses pneumatic cutting round knife, which is adjusted simply and pressed evenly.
- Paper pleating machine equips the pre-heating and water steam device, to prevent the paper breaking when roller marking.
- This filter machine equips the gear collecting system, so to faster the pleating speed and well pleated the paper.
- High automatic machine has the process of the process of the auto count marking,pleating,pre-heating and forming.
- Computer control and simple operation.
| Filter Machine info. | Filter Paper Pleating Machine BK-PLGT-600N |
| Specification | 1. Product capability:0~35m/min
2. Max.width:600mm 3. Min.width:50mm 4. Max.pleat height:70mm 5. Min.pleat height:10mm 6. Customize the rollers sizes 7. Temp.control: normal temp.~300oC 8. Main power:12kw 9. Working air pressure:0.6MPa 10. Power supply:380V/50Hz 11. M/C weight:750kg 12. M/C dimension:5200×1190×1170mm(L×W×H) |
| Components | 1. Auto paper de-coiler
2. Paper Pre-slitting machine 3. Pre-heating device before pleating 4. Auto counter 5. Water steam device 6. The specification of the drum can be changed arbitrarily 7. Roller and gear collecting device 8. Pleated paper heat forming and conveyor device |
| Box Size | |
| Payment Term | FOB, CFR, CIF, EXW, FCA, Express Delivery
T/T 30% as deposit, and 70% before delivery. |
| Shipping Port | Shenzhen, Tianjin, Ningbo |
| Delivery Time | 30-60 days, depend on your quantity and deposit |
| MOQ & Packing | Air Filter / Cabin Filter – MOQ: 200pcs , White box only; over 500pcs can do color box
Oil Filter / Fuel Filter – MOQ：500pcs , White box only; over 1000pcs can do color box Filter Paper – MOQ：3000KG Filter Machine – MOQ：1/Set, Packing：Export Standard Wood Carton |
Company Information
We have been manufacturing automotive filters for more than 20 years.
We focus on your demand,striving to the best cooperating opportunity with you.
BUKET people save you from the troubles and energy of seeking and identifying the quality filter products.
